    11.8KW 2600rpm 1.8 Ton Mini Excavator Small Digger Machine For Farm

    Ask Lasest Price
    Brand Name : TOROS
    Model Number : TE-18S
    Certification : CE\EPA\EURO 5
    Price : $11000-$12000 1 PCS
    Payment Terms : L/C, D/A, D/P, T/T, Western Union,
    Supply Ability : 100 PCS/Week
    Delivery Time : 30 Work Days
    • Product Details
    • Company Profile

    11.8KW 2600rpm 1.8 Ton Mini Excavator Small Digger Machine For Farm

    Hot selling mini excavators support factory customization

    The one-year free warranty service for this model has started!

    Click The Inquiry Below To Get The Best Price!

    The excavator is small & flexible, and cost-effective. It is equipped with a cab to protect the safety of the driver. It is characterized by advanced design, compact structure, reliable performance, easy start, low fuel consumption and noise. Thus, they are the best choice for home and small works applications for the environmentally conscious user. With quick hitch and different accessories, it is friendly and versatile, such as small earthwork, crushing stones and demolition, drilling piles, etc.

    11.8KW 2600rpm 1.8 Ton Mini Excavator Small Digger Machine For Farm


    Total measurement
    Total length*width* height(during transportation)3300*1110*2360 mm
    Dozer blade width (extend/retract)1110 mm
    Dozer blade height270 mm
    Track center distance883 mm
    Boom height2635 mm
    Standard track shoe width230 mm
    Standard bucket width (with/without side teeth)440/ 400 mm
    Track length1450 mm
    Wheel spacing1120 mm
    Distance from the center of rotation to the tail of the track745 mm
    Scope of work
    Maximum digging height3310 mm
    Maximum unloading height2370 mm
    Maximum digging depth2120 mm
    Maximum vertical boom digging depth1535 mm
    Maximum digging distance3640 mm
    Maximum digging distance3570 mm
    Minimum radius of gyration of the front section1660 mm
    Maximum bulldozing height260 mm
    Maximum bulldozing depth190 mm
    The minimum radius of gyration at the rear end715 mm
    Bucket moves horizontally to the left480 mm
    Bucket moves horizontally to the right410 mm
    Performance parameter
    Total Weight1550kg/1730 kg
    Bucket capacity0.04 m3
    engine modelD902
    Displacement0.898 L
    rated power11.8 KW/2600rpm
    Swing speed9 r/min
    Gradeability58(30)°
    Ground pressure27 kpa
    Bucket digging force13.8 KN
    Fuel tank capacity18 L
    Swing angle55(53)°
